華納精密軸承：一家專門從事精密,薄壁軸承的研發，生產型企業。

KG140XP0|KG140CP0|KG140AR0|KG140XPO|KG140CPO|KG140ARO

作者：發布時間：2018-11-02 瀏覽次數：2510

打印收藏關閉

		Dimensions in Inches				Capacities (lbs)1		Approx.
part		Bore	Outside	Land	Land	Dynamic	Static2	weight
number			dia.	dia.	dia.	Dynamic	Static2	(lbs)
				L1	L2	Kaydon	Radial
						radial	Radial
KG040XP0	KG040CP0	4	6	4.742	5.258	6,115	8,210	3.6
KG042XP0	KG042CP0	4.25	6.25	4.992	5.508	6,061	8,210	3.8
KG045XP0	KG045CP0	4.5	6.5	5.242	5.758	6,227	8,760	4
KG047XP0	KG047CP0	4.75	6.75	5.492	6.008	6,487	9,300	4.1
KG050XP0	KG050CP0	5	7	5.742	6.258	6,691	9,850	4.3
KG055XP0	KG055CP0	5.5	7.5	6.242	6.758	6,850	10,400	4.7
KG060XP0	KG060CP0	6	8	6.742	7.258	7,241	11,490	5.1
KG065XP0	KG065CP0	6.5	8.5	7.242	7.758	7,393	12,040	5.4
KG070XP0	KG070CP0	7	9	7.742	8.258	7,764	13,130	5.8
KG075XP0	KG075CP0	7.5	9.5	8.242	8.758	7,911	13,680	6.1
KG080XP0	KG080CP0	8	10	8.742	9.258	8,265	14,770	6.5
KG090XP0	KG090CP0	9	11	9.742	10.258	8,743	16,420	7.2
KG100XP0	KG100CP0	10	12	10.742	11.258	9,204	18,060	7.9
KG110XP0	KG110CP0	11	13	11.742	12.258	9,648	19,700	8.6
KG120XP0	KG120CP0	12	14	12.742	13.258	10,074	21,340	9.3
KG140XP0	KG140CP0	14	16	14.742	15.258	10,886	24,620	10.8
KG160XP0	KG160CP0	16	18	16.742	17.258	11,648	27,910	12.3
KG180XP0	KG180CP0	18	20	18.742	19.258	12,367	31,190	13.7
KG200XP0	KG200CP0	20	22	20.742	21.258	13,044	34,470	15.8
KG220XP0	KG220CP0	22	24	22.742	23.258	13,685	37,757	16.8
KG250XP0	KG250CP0	25	27	25.742	26.258	14,591	42,680	19.5
KG300XP0	KG300CP0	30	32	30.742	31.258	15,963	50,890	23.3
KG350XP0	KG350CP0	35	37	35.742	36.258	17,195	59,100	27.1
KG400XP0	KG400CP0	40	42	40.742	41.258	18,307	67,310	30.8

本文是【http://www.zkhjcp.com 洛陽華納精密軸承科技有限公司】原創(chuàng )，轉載時請務必以鏈接形式注明作者和出處

上一篇：沒有了

下一篇：JU060CPO|JU060XPO|JU060XP0|JU060CP0軸承現貨
